Indicating snap gage Marameter 840 FC
| Product number: | 4450100KAL |
|---|
Indicating snap gage Marameter 840 FC
Measuring range : mm
Material Contact surface: ceramic
Package contains: flat contact point 903 (steel), instruction manual, wooden case, excludes indicator
Measuring range : mm
Material Contact surface: ceramic
Package contains: flat contact point 903 (steel), instruction manual, wooden case, excludes indicator
Product price
1.339,25 €
Application
- For cylindrical parts such as shafts, bolts and spindles
- For thickness and length measurements
- Universally applicable and extremely versatile
- Each instrument spans a broad measuring range
- Any dimension and fit can be very quickly and easily adjusted
Product features
- Rugged, forged steel frame with heat insulators
- Measuring spindle is mounted in long guideway with lever controlled retraction
- Measuring spindle and anvil spindle are both made of hardened stainless steel, ceramic measuring faces
- Adjustable centering stop for surface centering
- Anvil spindle can easily be fine adjusted
- Constant measuring force as a result of built-in spring, eliminating user influence
- Maximum wear resistance due to non-contact positioning in conjunction with carbide tipped measuring faces in connection with ceramic measuring faces
Material Contact surface
ceramic
Scope of delivery
flat contact point 903 (steel), instruction manual, wooden case, excludes indicator
Marameter 840 FC | Art. no. 4450100KAL
Dimensions
a 5 mm | b 97 mm | c 34 mm | d 8 mm | e 54 mm | f 65 mm | g 12 mm | h 13 mm | k 23 mm | l 14 mm |
