Mechanical dial comparator Millimess 1010
| Product number: | 4332000 |
|---|
Dial comparator Millimess 1010
Factory standard
Measuring range : ± 0.25 mm
Readings: 0.01
Package contains: test certificate, case
Factory standard
Measuring range : ± 0.25 mm
Readings: 0.01
Package contains: test certificate, case
Product price
149,00 €
Product features
- Large, high contrast dial face
- Adjustable tolerance markers
- Lockable fine adjustment screw
- Shockproof movement
- Mounting shank and measuring spindle are both made of hardened stainless steel
- Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
- Resistant to lateral forces (side play) acting on the measuring spindle
- Maximum sensitivity and accuracy are ensured by the jeweled movement in conjunction with the precision gears and pinions
- Box type protective housing
- Constant measuring force
- Measuring spindle can be retracted with either a screw in cable release or with a lifting knob
Scope of delivery
test certificate, case
Millimess 1010 | Art. no. 4332000
